IEC 60335 Toaster Test System 500 Automatic Cycles for Appliance Safety & Reliability

Name: IEC 60335 Toaster Test System 500 Automatic Cycles for Appliance Safety amp Reliability
Brand: Sinuo
Price: 1 USD

Wholesale IEC 60335 Toaster Test System 500 Automatic Cycles for Appliance Safety & Reliability from china suppliers

Brand Name : Sinuo

Model Number : SN1116

Certification : Calibration Certificate (Cost Additional)

Place of Origin : China

MOQ : 1

Price : Customized

Payment Terms : T/T

Supply Ability : 20 Sets Per Month

Delivery Time : 30 Days

Packaging Details : Plywood Case

Applied Standard : IEC 60335-2-9

Applied Clause : Clause 19.101

Test Station : Single

Drive Mode : Electrical

Baking Cycles : 0-9999

Test Times : 0-9999

Interval Time : 0-99.9s

Control Method : PLC control

Contact Now

IEC 60335 Toaster Test System 500 Automatic Cycles for Appliance Safety & Reliability

Product information:

The test appliance conforms to IEC60335-2-9: 2016 “Household and similar electrical appliances - Safety - Part 2-9: Particular requirements for grills, toasters and similar portable cooking appliances” clause 19.101.

It is used to test toasters’ breaking capacity and endurance that toasters are operated at rated power input and under normal operation.

The switch on and off of the toaster is automatically realized by using the drive mechanism, after each test time, for six cycles of operation, the toaster is forced to cool to approximately room temperature. This test is carried out 500 times. The test equipment will stop testing automatically after the preset test times are reached.

Technical Parameters:

Input Power Supply	220V, 50Hz
Test Station	Single
Electrical Control Method	Integrated PLC and touch screen
Drive Mode	Electrical
Sample Clamping Method	Mechanical clamping, the position of clamping point is adjustable
Cooling Method	Forced cooling by high-power cooling fan
Temperature Measuring Device	Infrared temperature measurement system, when the infrared probe detects that the temperature is cooled to the set temperature, the next test is started.
Interval Time of Pushing Switch	0-99.9s, can be preset
Baking Cycles	0-9999,can be preset, default 6 cycles
Test Times	0-9999,can be preset, default 500 times
Current Detecting Device	It is equipped with a device for automatically detecting the working current of the specimen: the upper and lower limits of the current detection can be adjusted, and with a light indicator indicating status.

Operation steps:

A. Preset the interval, test cycle and test time, preset the room temperature and press [RESET].

B. Insert the specimen plug into the socket of the test equipment, press the START button to start the timer, and when the interval display reaches the set value, the switch operator goes out. The system calculates one test cycle. When the switch operator turns on the toaster switch and the toaster begins to heat, the switch operator runs up to the upper limit position. After completing the preset test cycles (default 6), the system calculates the test time and turns on the fan to cool the toaster. After the test time reaches the preset value, the test equipment will stop testing.

IEC 60335 Toaster Test System 500 Automatic Cycles for Appliance Safety & Reliability
